Machine guarding for machining equipment: drill presses, mills, lathes, saws, grinders, CNC routers, plasma and waterjet machines, EDM and more.
Showing all 58 products
Machine tools differ in size and purpose, but their hazards repeat from one machine to the next. The point of operation is where the tool meets the work. Rotating parts such as chucks, spindles, arbors and drawbars can wrap a sleeve, glove or hair. Ingoing nip points form wherever a belt runs onto a pulley or material feeds between rollers. The cut throws chips, coolant and sparks, and a damaged grinding wheel can burst into fragments. Many older machines also restart on their own when power returns after an outage, a hazard that a physical guard alone does not address.
Walk each machine and list its hazard zones: the cutting area, the chuck or spindle, the drive, the back of the machine where chips land, and the controls. Fit a fixed guard wherever no one needs access during production, and an adjustable or interlocked guard wherever operators load parts, change tools or measure. Clear polycarbonate lets operators watch the cut with the guard closed. Older machines without modern controls can take anti-restart and motor brake systems or machine interlock systems, and a machine risk assessment helps rank the work across a plant.
OSHA’s general machine guarding rule, 1910.212, applies to every machine in this section. 1910.212(a)(1) requires guarding that protects operators and others nearby from point of operation hazards, ingoing nip points, rotating parts, flying chips and sparks. 1910.212(a)(2) requires guards to be affixed to the machine where possible and never to create a hazard themselves, and 1910.212(a)(3)(ii) requires the point of operation to be guarded. Milling machines are on OSHA’s list of machines that usually require point of operation guarding, and abrasive wheel machinery has its own rule, 1910.215. Among consensus standards, ANSI B11.0 sets out risk assessment and risk reduction for machinery, ANSI B11.8 covers manually controlled milling, drilling and boring machines, and ANSI B11.23 covers machining centers and automatic numerically controlled milling, drilling and boring machines. See the B11 series overview for other machine-specific standards.
Any machine whose operation can injure the operator or people nearby. OSHA 1910.212 requires guarding against point of operation hazards, ingoing nip points, rotating parts, flying chips and sparks, and lists milling machines and power saws among the machines that usually need point of operation guarding. Drill presses, lathes and grinders present the same rotating-part and flying-chip hazards.
Not necessarily. A chip shield keeps chips and coolant away from people but may leave the cutter, chuck or spindle within reach. A guard has to keep hands out of the hazard zone. Many machines need both: a guard or interlocked enclosure at the point of operation, and shields where chips leave the machine.
Use a fixed guard where no one needs access during production. Where operators open the guard to load parts, change tools, measure or clear chips, an interlocked guard stops the motion or keeps the machine from starting while it is open. The risk assessment process in ANSI B11.0 helps decide which guard each task needs.
Yes. Several Odiz guards are adjustable, such as the long-reach radial arm drill guard, which is designed to fit older machines, and the UFIT lathe chuck guards, which you adjust to your machine. Custom guards are built to the machine's measurements, and power-loss drop-out and interlock controls can be added to machines that would otherwise restart by themselves after an outage.
