Custom safety-rated electrical enclosures for continuous flow lines and interlocked machine guards.
Showing all 2 products
A safety-rated electrical enclosure is the control cabinet that ties a machine’s safety devices together. It typically holds the circuit protection, contactors, power supply and a safety relay or safety controller, with start, stop, E-stop and reset buttons and status lights on the door or close by. When an E-stop is pressed, a light curtain is interrupted or an interlocked guard opens, the safety circuit removes power from the hazardous motion and is designed to keep it off until a deliberate reset.
The custom continuous flow line safety-rated electrical enclosure is a compact, floor-mounted cabinet purpose-built for continuous flow lines, with circuit protection, clean internal wiring and operator interface components. At the scale of a single machine, the Odiz interlock system offered with the flip-up or side-swinging drill press guard packages start/stop/E-stop controls, no restart on power loss and an LED guard indicator with the guard itself.
ISO 13849-1 covers the design of the safety-related parts of a control system, with each safety function rated by performance level, and ISO 13849-2 covers validating that design by analysis and testing. ANSI B11.26 gives requirements and guidance for safety-related control functions across electrical, electronic, pneumatic, hydraulic and mechanical components. NFPA 79, the electrical standard for industrial machinery, covers a machine’s electrical equipment from the point where the supply conductors connect to it.
Before safety devices are added to an older machine, Odiz electrical validation services can document the existing controls and identify where interlocks and safety switches should connect. Related: anti-restart and motor brake systems, emergency stop controls and engineering and design.
It is the safety circuit inside, not the cabinet itself. A safety-rated enclosure uses components such as safety relays or controllers, monitored contactors and E-stop devices, wired so each safety function performs at the level the risk assessment requires, and the design is then validated by analysis and testing.
Flow lines and retrofits often have more stations, safety inputs and loads than a standard start/stop box can handle. A custom build sizes the circuit protection, contactors and safety controller to the machine, puts E-stops and reset buttons where operators work, and fits the mounting space available.
The machine or line layout, supply voltage, motor sizes, every safety device to be monitored, where operators stand and the mounting location. Photos of the machine and any existing control panel help, and a risk assessment defines the safety functions the enclosure must perform.
