22mm Start(NO)/Stop(NC)/EStop(NC) – Button Only
$149.00
| Weight | 1.89 lbs |
|---|---|
| Dimensions | 3.35 × 3.15 × 7.09 in |
The 22PBA3-N4P-303-00 is a compact 3-hole, 22 mm operator station designed for industrial control panels. It includes:
-
A flush green START pushbutton
-
An extended red STOP pushbutton
-
A mushroom-style E-STOP pushbutton
All buttons are mounted in a rugged NEMA 4X-rated plastic enclosure, with one normally-open (NO) and two normally-closed (NC) contacts per actuator, and UL-listed components for reliable, watertight operation in harsh environments.
Not sure where to start? Reach out to our team to learn more.
To request more information about this product or service, please complete the form below. You can also chat live with one of our specialists via the widget in the bottom-right corner of your screen or call us at (574) 318-4333.
The 22PBA3-N4P-303-00 is a rugged, three-hole, 22 mm operator station kit designed to give you a complete control-panel interface in a single assembly. It includes three high-visibility pushbuttons: a flush green “START,” a raised red “STOP,” and a large, mushroom-style E-STOP for rapid shutdown. Each operator comes with factory-installed contact blocks (one normally-open and two normally-closed) for versatile hookup to both control and safety circuits.
All components mount into a watertight NEMA 4X-rated polycarbonate enclosure, providing IP66 protection against dust, water spray and corrosive environments. The enclosure measures approximately 7.09 in (depth) × 3.15 in (width) × 3.35 in (height), making it easy to integrate into standard panels or cabinets. Legend plates are included for clear START/STOP identification, and all necessary mounting hardware simplifies on-site assembly and wiring.
The emergency-stop pushbutton meets ISO 13850 requirements with dual NC contacts to ensure safe, monitored shutdown of machinery. The compact footprint and robust construction make this station well suited for almost any industrial or outdoor automation application—from conveyor controls and motor starters to pump systems and test stands—where reliability, ease of use, and environmental resistance are critical.
